U2-1018S-PF

U2-1018S-PF
  • Combination Viewing Head/Signal Processor
  • Model : U2-1018S-PF
  • Sensor Type : UVTron/IR
  • Factory installed cable. Suitable for all fuels.
  • Input power: 22-26 VDC, 120 mA max
  • Output relay contacts: one normally open flame relay and one normally open fault/self-check relay, 1A, 30 VDC.
  • Ambient temperature: -40°F to 158°F (-40°C to 70°C).
  • Control model: Flame switch
  • Enclosure: IP66, 1" NPT mounting.
  • Analog flame signal: 0-20 mA or 4-20 mA output
  • Brand : Honeywell
  • U2S Series Data Sheet
  • U2-1018S-PF (1)
  • U2-1018S-PF (2)
  • U2-1018S-PF (3)
  • U2-1018S-PF (4)
  • U2-1018S-PF (5)
  • U2-1018S-PF (6)
  • U2-1018S-PF (7)
  • U2-1018S-PF (8)
  • U2-1018S-PF (9)
