applications:
be suitable to vacuum brazing of stainless steel,titanium alloy,superalloy,hard alloy and colored metal.
characteristics:
1. small deformation, perfect uniformity of temperature, stable mechanical movement, short time of recovery of vacuum, high production efficiency, low cost, simple operation, flexible input of programming process.
2. manual/semi-automatic/automatic control.
3. automatic fault alarm/display.
4. inner/outer circle cooling.(optional)

model:	availability dimension(mm)	load capacity(kg)	heat material	power(kw)	max temperature(℃)	temperatrue equality(±℃)	limit vacuum degree(pa)	press ascend rate(pa/h)	gas cooling pressure(bar)
vbf-40	450×300×300	100	graphite	40	1300	5	4×10-3	0.67	2
vbf-50	600×400×400	200	graphite	80	1320	5	6×10-3	0.67	2
vbf-80	600×400×400	200	molybdenum	80	1300	5	4×10-3	0.67	2
vbf-120	750×500×500	300	molybdenum	120	1300	5	4×10-3	0.67	2
vbf-150	900×600×600	500	graphite	150	1320	5	6×10-3	0.67	2
vbf-160	900×600×600	500	molybdenum	200	1250	5	6×10-3	0.67	2
vbf-200	1200×600×600	800	graphite	200	1250	5	6×10-3	0.67	2
vbf-200	1100×700×700	500	graphite	200	1300	5	4×10-3	0.67	2
